Madblondedog - it was fine especially as we used a design that (I think) Magnet came up with!
I think it's all about symmetry - we had 2m to play with so on the side that people see (the first photo) side it's a 1000 3xDrawer flanked by 2x500 cupboards. On the other side (which is the more functional side and is less immediately visible) it's a 450 cupboard, a 300 wine cooler, an 800 3 drawer and another 450 cupboard. The 450s and the 500s on the ends are what give it symmetry.
When you input it to DIYK, its asks you to select the the door hanging side for all units so they come with the door already in the right place. You can also input a unit name so for instance, I input Island Unit 1, Island Unit 2 etc. That made it easier when everything arrived as I gave a plan to the fitter with the unit number on it. Another thing with islands is to include some sort of end panel and we went for 4 tongue and groove end panels (two for each end) to give it some interest.
Having an appliance in there can make it slightly more difficult as you should really have an end panel either side of it to give the kick boards something to but up against but that adds 2 x 18mm to the island length that you'd have to add into the other side by inserting an 18mm end panel at either end of the run. I didn't bother and you don't notice it and the kick board stays in place via the supplied clips anyway.
You have to be a bit careful with the island in terms of the aisle width when it's opposite something like an oven or a dish-washer as you need to allow for the door to open and stay in front of it. Ours in 1200m which feels huge - I think the minimum guide is 900mm.
As I say - I didn't come up with any of this lot - TBH, it was an amalgam of many visits to several retailers and homing in on a design over a period of months that I then got one of them to produce me a plan for. You have to put up with the retailers calling you up for a bit to ask whether you've made your decision yet but they get the message after a while and leave you alone (embarrassing I know!)
Thanks for the compliment by the way, the dog was chuffed
